绝缘胶带
| Product P/N | Total Thickness(μm) | Type | Carrier |
180° Peel Strength (N/25mm,SUS) |
Color |
DC Breakdown Voltage(KV) |
Adhesive Type | Feature/Application |
| SG 8811 | 10 | Single-Sided | Polyimide Film | ≥8 | Matte Black | ≥1.0 | Acrylic |
1.
Designed for Lightproof and insulation applications 2.High Temperature resistance |
| SG 8882 | 22 | ≥8 | Amber | ≥1.0 | ||||
| SG 8812 | 30 | ≥10 | Matte Black | ≥1.0 | ||||
| SG 8813 | 50 | ≥10 | Matte Black | ≥2.0 | ||||
| SG 8814 | 80 | ≥18 | Matte Black | ≥4.0 | ||||
| SG 8815 | 180 | ≥25 | Matte Black | ≥7.0 | ||||
| SG 8819 | 45 | ≥10 | Black | ≥1.0 | ||||
| SG PT003M | 30 | ≥7 | Black | ≥1.0 | ||||
| SG PT004M | 40 | ≥8 | Black | ≥1.0 | ||||
| SG 8821 | 50 | Single-Sided | Acetate Cloth | >12 | Black | ≥3.2 | Acrylic | Insulation material that can provide good temperature, solvent and age degradation resistance |
| SG 8822 | 100 | >13 | Black | ≥5.5 | Acrylic | |||
| SG 8823 | 220 | >16 | Black | ≥9.0 | Acrylic | |||
| SG 8830 | 60 | Single-Sided | Polyester Film | >10 | Yellow | ≥3.0 |
Acrylic&Rubber Thermosetting Adhesive |
Excellent Electrial insulation |
| SG EIA0040 | 40 | Single-Sided | Aramid Paper | >13 | Black | ≥4.0 | Acrylic |
1.Excellent
electrical insulation and chemical resistance and high-temperature
durability. 2. It's much softer than other insulation tape. |
| SG EIA0050 | 50 | Single-Sided | >13 | Black | ≥4.0 | |||
| SG EIA0060 | 60 | Single-Sided | >13 | Black | ≥4.0 | |||
| SG EIA0100 | 100 | Single-Sided | >15 | Black | ≥4.0 | |||
| SG EIA0150 | 150 | Single-Sided | >15 | Black | ≥4.0 | |||
| SG EIA0200 | 200 | Single-Sided | >15 | Black | ≥4.0 | |||
| SG SNT0050 | 50 | Single-Sided | >12 | White | ≥4.0 | |||
| SG SNT0100 | 100 | Double-Sided | >18 | Black | ≥4.0 | |||
| SG SNT0100B | 100 | Double-Sided | >18 | Black | ≥4.0 | |||
| SG SNT0200 | 200 | Single-Sided | >12 | Black | ≥4.0 | |||
| SG 8850 | 22 | Single-Sided | Polyester Film | >8 | Clear/Black | ≥5.0 | Acrylic | Excellent adhesive strength and excellent voltage resistance performance |
| P1200 | 40-600 | Single-Sided | PTFE | >10 | Black/Greyish white/brown | ≥10.0 | Acrylic/Silicone |
1. Excellent electric insulation
performance and abrasion resistance. 2. High temperature resistant (-60~200°C) |
